Imtra Marine Products

Imtra LED Linear Lights on this webpage (FREE SHIPPING OVER $100*):
Resolux 801 Surface Mount Linear LED Lights
Resolux 805 Surface Mount Linear LED Lights
Resolux 805 High Output Surface Mount Linear LED Lights
Resolux 851, 852 and 853 Surface Mount Linear LED Lights with Switch
Resolux 505 Elegance Surface Mount Linear Fluorescent and LED Light
Resolux 551 Surface Mount Linear LED Light
For more information regarding LED Lighting

Resolux 801 Surface Mount Linear LED Lights by Imtra Marine Lighting

Click for larger image

Imtra Marine Lighting


Resolux 801 Surface Mount Linear LED Light Diagram by Imtra Marine Lighting

RESOLUX 801 SURFACE MOUNT LINEAR LED LIGHTS BY IMTRA The dimmable Resolux 801 Surface Mount Linear LED Light offers high luminous intensity in a compact housing, making it the ideal alternative to dated fluorescent fixtures often installed in a galley or head. Using the 3rd wire (supplied), it provides seamless dimming function when used with Imtra's ILIM80110 PWM Dimmer Module and any "normally open" SP/ST momentary switch. Its ability to be installed in a wet environment (with an IP67 rating) makes the possible applications of this light endless. Please read regarding Maryland, Massachusetts and Washington shipments sales tax. Made in USA.

    Features & Benefits: Aluminum housing with impact resistant ABS end caps · Multi-voltage: 11-30VDC · PWM Dimmer interface · No recessed depth requirements · Maintenance free - No bulbs to change · Low power consumption
US$104.95 / EACH
  • Finish: White Powder Coat
  • Housing Material: Die Cast Anodized Aluminum
  • End Caps Material: White ABS
  • Dimensions (L x W x H): 7.54" x 1.93" x 0.6" (191.6 x 49.1 x 15.3 mm)
  • Voltage: 11-30VDC
  • Power Consumption: 5W
  • LED Engine: 3 x 1W Osram LEDs, Cool White or Warm White
  • Luminous Intensity: 130 Lumens Warm, 165 Lumens Cool
  • Kelvin Temp: 3000K Warm, 4000K Cool
  • CRI: 80 Warm
  • Working Life (L70): 20,000 hours
  • Wire Size: See Chart
  • Electrical Protections: Reverse Polarity
  • Integral Switch: No
  • Dimmer Module: See ILIM80110
  • Mounting Method: Surface-mount (with screws)
  • Ingress Protection: IP67
  • Manufacturer: Frensch
  • Weight: 0.30 lbs.
  • Part Number: IL6305 / IL6304
  • Resolux 805 Surface Mount Linear LED Lights by Imtra Marine Lighting

    Click for larger image

    Imtra Marine Lighting


    Resolux 805 Surface Mount Linear LED Light Diagram by Imtra Marine Lighting

    RESOLUX 805 SURFACE MOUNT LINEAR LED LIGHTS BY IMTRA The Resolux 805 Surface Mount Linear LED Light fixture is the ideal solution for upgrading older fluorescent fixtures with the latest power saving technology. Its linear LED engine delivers a wide beam angle with high luminous intensity in a choice of warm or cool LED color. No more delicate fluorescent bulbs to change! Its good looks and rugged construction make it perfect for on board living. Its ability to be installed in a wet environment (with an IP65 rating) makes the possible applications of this light endless. Please read regarding Maryland, Massachusetts and Washington shipments sales tax. Made in USA.

      Features & Benefits: Aluminum housing with impact resistant ABS end caps · Wide beam angle · No recessed depth requirements · Maintenance free - No bulbs to change · Low power consumption
    US$104.95 / EACH
  • Finish: White Powder Coat
  • Housing Material: Die Cast Anodized Aluminum
  • End Caps Material: White ABS
  • Dimensions (L x W x H): 13.8" x 1.93" x 0.6" (350.6 x 49 x 15.3 mm)
  • Voltage: 12VDC or 24VDC
  • Power Consumption: 4.5W
  • LED: 36 x PLCC2 LEDs Cool White or Warm White
  • Beam Angle: 100°
  • Luminous Intensity: 175 Lumens Warm, 200 Lumens Cool
  • Kelvin Temp: 3000K Warm, 4500K Cool
  • CRI: 70
  • Working Life (L70): 20,000 hours
  • Wire Size: See Chart
  • Electrical Protections: Reverse Polarity
  • Integral Switch: No
  • Mounting Method: Surface-mount (with screws)
  • Ingress Protection: IP65
  • Manufacturer: Frensch
  • Weight: 0.52 lbs.
  • Part Number: IL6261 / IL6262 / IL6257 / IL6258
  • Resolux 805 High Output Surface Mount Linear LED Lights by Imtra Marine Lighting

    Click for larger image

    Imtra Marine Lighting


    Resolux 805 High Output Surface Mount Linear LED Light Diagram by Imtra Marine Lighting

    RESOLUX 805 HIGH OUTPUT SURFACE MOUNT LINEAR LED LIGHTS BY IMTRA The 8W Resolux 805 HO (High Output) Surface Mount Linear LED Light has the same surface-mount linear form factor as the 4W Resolux 805 LED fixture (see above) but delivering twice the brightness to illuminate larger surface areas from greater elevations. The 805 HO is the ideal solution for upgrading older fluorescent fixtures with the latest power saving technology. Its linear LED engine delivers a wide beam angle with high luminous intensity in a choice of warm or neutral LED color. No more delicate fluorescent bulbs to change! Its good looks and rugged construction make it perfect for on board living. Please read regarding Maryland, Massachusetts and Washington shipments sales tax. Made in USA.

      Features & Benefits: Aluminum housing with impact resistant ABS end caps · Wide beam angle · No recessed depth requirements · Maintenance free - No bulbs to change · Low power consumption
    US$139.95 - $144.95 / EACH
  • Finish: White Powder Coat
  • Housing Material: Die Cast Anodized Aluminum
  • End Caps Material: White ABS
  • Dimensions (L x W x H): 13.8" x 1.93" x 0.6" (350.6 x 49 x 15.3 mm)
  • Voltage: 10-30VDC
  • Power Consumption: 8W
  • LED: 24 x High Output LEDs Neutral White or Warm White
  • Beam Angle: 100°
  • Luminous Intensity: 275 Lumens Neutral, 250 Lumens Warm
  • Kelvin Temp: 4000K Neutral, 3000K Warm
  • CRI: 70
  • Working Life (L70): 20,000 hours
  • Wire Size: See Chart
  • Electrical Protections: Reverse Polarity
  • Integral Switch: With Switch (IL6582 or IL6584) or Without Switch (IL6581 or IL6583)
  • Mounting Method: Surface-mount (with screws)
  • Ingress Protection: IP40
  • Manufacturer: Frensch
  • Weight: 0.52 lbs.
  • Part Number: IL6581 / IL6583 / IL6582 / IL6584
  • Resolux 851, 852 and 853 Surface Mount Linear LED Lights with Switch by Imtra Marine Lighting

    Click for larger image

    Imtra Marine Lighting


    Resolux 851, 852 and 853 Surface Mount Linear LED Light with Switch Diagram by Imtra Marine Lighting

    RESOLUX 851, 852 and 853 SURFACE MOUNT LINEAR LED LIGHTS WITH SWITCH BY IMTRA The Resolux 851, 852 and 853 Surface Mount Linear LED Light with Switch combines new high output LED technology with illuminated one touch dimming feature in various lengths to suit any application. Whether you're installing for under-cabinet lighting in the galley or in the nearby hanging locker, the Resolux 850 offers complete versatility encompassing full dimmability, low profile housing, and 270 degree rotation for direct lighting. Please read regarding Maryland, Massachusetts and Washington shipments sales tax. Made in USA.

      Features & Benefits: Solid-state circuitry: Shock and vibration proof · Integrated drive electronics - No complicated wiring · Multi-voltage for 12V or 24V systems · No radiated heat - Safe to touch · Push button dimming interface: various light output choices
    US$119.95 - $279.95 / EACH
  • Finish: White Powder Coat
  • Housing Material: Die Cast Anodized Aluminum
  • End Caps Material: White ABS
  • Dimensions (L x W x H): 7.76" x 1.26" x 1.38" (197 x 32 x 35mm)
  • Voltage: 11-30VDC
  • Power Consumption: Resolux 851 = 350mA @ 12V / 170mA @24V
  • Power Consumption: Resolux 852 and Resolux 853 = 700mA @ 12V / 340mA @24V
  • LED Engine: Resolux 851 = 3 x 1W, Resolux 852 = 6 x 1W, Resolux 853 = 9 x 1 W Warm White
  • Beam Angle: 45°
  • Luminous Intensity: Resolux 851 3 x 1W = 150 Lumens, Resolux 852 6 x 1W = 300 Lumens, Resolux 853 9 x 1W = 450 Lumens
  • Kelvin Temp: 3000K
  • CRI: 80
  • Working Life: 50,000 hrs
  • Wire Size: See Chart
  • Electrical Protections: Reverse Polarity
  • Integral Switch: Yes
  • Dimmer Interface: Yes (PWM type)
  • Mounting Method: Surface-mount (with screws)
  • Ingress Protection: IP40
  • Manufacturer: Frensch
  • Weight: 0.3 lbs.
  • Part Number: IL6315 / IL6317/ IL6319


  • Click for larger image

    Imtra Marine Lighting


    Resolux 851, 852 and 853 Surface Mount Linear LED Light with Switch Diagram by Imtra Marine Lighting

    RESOLUX 505 ELEGANCE SURFACE MOUNT LINEAR FLUORESCENT AND LED LIGHTS WITH SWITCH BY IMTRA The Resolux 505 Elegance Surface Mount Linear LED Light has a flicker-free soft start feature, assuring long lamp life, with 6 LEDs mounted in the center. Switches from fluorescent tube to the energy-saving night light using a toggle switch. Please read regarding Maryland, Massachusetts and Washington shipments sales tax. Made in USA.

    US$91.95 / EACH
  • Finish: White ABS Plastic Housing
  • Dimensions (L x W x H): 15.55" x 2.28" x 1.37" (395 x 58 x 35mm)
  • Bulb Color: Warm White T5 with 6 x Red LEDs
  • Voltage: 12VDC or 24VDC
  • Amp Draw: 0.68A/60mA
  • Wattage: 8W
  • Switch Included: Yes
  • Wire Size: See Chart
  • Ingress Protection: IP40
  • Weight: 1.0 lbs.
  • Part Number: IL5241 / IL5242
  • Resolux 551 Surface Mount LED Lights by Imtra Marine Lighting

    Click for larger image

    Imtra Marine Lighting

    Resolux 551 Surface Mount LED Light Diagram by Imtra Marine Lighting

    RESOLUX 551 SURFACE MOUNT LINEAR LED LIGHTS BY IMTRA The Resolux 551 Surface Mount Linear LED Light is housed in a white glass fiber-reinforced polycarbonate casing with 6 LEDs mounted in the center. Please read regarding Maryland, Massachusetts and Washington shipments sales tax. Made in USA.

    US$29.95 - $39.95 / EACH
  • Housing: Glass Fiber-Reinforced Polycarbonate, White
  • Dimensions (L x W x D): 4.9" x 1.22" x 0.55"
  • Light source: 6 x 5mm LED
  • LED color: Cool White, Red or Blue
  • Voltage: 12VDC
  • Wire Size: See Chart
  • Ingress Protection: IP67
  • Weight: 0.09 lbs.
  • Part Number: IL5254 / IL5255 / IL5256 / IL5257 / IL5258 / IL5259
