Imtra Marine Products

Imtra LED Dimmers on this webpage (FREE SHIPPING OVER $100*):
Imtra PowerLED Analog Dimmer Module for PowerLEDs 0-10V
Imtra PowerLED Dimmer
Resolux 570 PowerLED Master Dimmers

Imtra PowerLED Analog Dimmer Module for PowerLEDs 0-10V

Click for larger image

Imtra Marine Lighting

IMTRA POWERLED ANALOG DIMMER MODULE FOR POWERLEDS 0-10V Imtra’s 0-10V PWM PowerLED dimmer is based on an analog lighting control protocol and is compatible with certain Lutron/Crestron 0-10V dimmer systems. This dimmer can accept an analog input (source) voltage of 0-10V, interpret that input, and output a corresponding PWM signal to control the lights' intensity. The LED lights will be at full brightness when the voltage is at 10V and at full dim when the voltage is 0 volts. The 0-10V PWM PowerLED Dimmer relies on a source dimmer control (e.g. Lutron NTF-10, or similar) for the voltage input representing user selected dimming level. The 0-10V PWM PowerLED Dimmer then outputs a PWM command signal to our PowerLED light fixtures, in same manner as our pushbutton controlled PowerLED dimmers.. Please read regarding Maryland, Massachusetts and Washington shipments sales tax.

Features & Benefits:
  • Allows Imtra PowerLEDs to Interface with Control Systems Providing 0-10VDC Analog Signal
  • Compact and Lightweight
  • Controls Up to 30 PowerLED Fixtures
  • Two (2) Year Limited Warranty
  • Installation Manual
  • Dimensional Drawing

  • US$129.95 / EACH
  • Integrated Switch: Determined by the control system used
  • Input Voltage: 12/24VDC
  • Dimensions: 2.68" x 1.39" x 0.72" (68 x 18 x 18mm) Including Flanges
  • Manufacturer: Imtra
  • Weight: 1.0 lb
  • Part Number: ILIM80200
  • PowerLED Dimmer by Imtra Marine Lighting

    Click for larger image

    Imtra Marine Lighting

    IMTRA POWERLED DIMMER Imtra’s model ILIM80120 (replaces ILIM80110) LED Dimmer Module provides dimming for all Imtra PowerLED Downlights (including Captiva) and supports several functions including digital PWM output and four modes of analog input including 0-10V Sink, 0-10V Sink/Source, 4-20mA, 10KΩ-100KΩ Potentiometer. Please read regarding Maryland, Massachusetts and Washington shipments sales tax.

    Features & Benefits:
  • Digital PWM Output Compatible with All Imtra PowerLEDs (Including Captiva)
  • Analog output: 0-10V Sink, 0-10V Sink/Source, 4-20mA, and 10KO-100KO Potentiometer
  • Space-Saving Compact Design
  • Easy to Identify Input/Output Wire Terminals
  • Works with Single or Double Throw Momentary Switches
  • Dipswitches for Customized Functions
  • One (1) Year Limited Warranty
  • Installation Manual
  • Dimensional Drawing
  • Compatibility Chart

  • US$124.95 / EACH
  • Housing Material: Flame Retardant ABS (UL94V-0)
  • Dimensions: 0.80" (20mm) H x 2.66" (68mm) W x 2.08" (53mm) Depth
  • Voltage Input: 10-40VDC
  • Capacity: 30 PowerLED Units
  • Base Dimensions: 2.66" (68mm) x 2.08" (53mm)
  • Power Consumption: 1W Max
  • Dimmer Compatibility: Imtra PowerLED Downlights (and Captiva)
  • Load Rating: 30 PowerLED Fixtures (Different Wattages)
  • Dimmer Control Interface: Single or Double Throw NO Momentary Push-buttons (Multiple, Wired In Parallel)
  • Mounting Method: Screw Mounting
  • Ingress Protection: IP40
  • Class: III
  • Certifications & Compliance: CE
  • Manufacturer: Imtra
  • Weight: 1.0 lb
  • Part Number: ILIM80120
  • Resolux 570 PowerLED Master Dimmers by Imtra Marine Lighting

    Click for larger image

    Imtra Marine Lighting

    Resolux 570 PowerLED Master Dimmer Diagram by Imtra Marine Lighting

    IMTRA RESOLUX 570 POWERLED MASTER DIMMER The Resolux 570 PowerLED Master Dimmer Module is a din-rail compatible compact PWM (Pulse-Width Modulation) LED dimmer for use with all Frensch brand dimmable F-Series PowerLED spots and dimmable Resolux Linear LED marine lighting fixtures. With a typical 12V system, the dimmer will control 20 x LED fixtures (and double this capacity with a 24V system). Compatible with any single-throw momentary switches. Made in Germany.. Please read regarding Maryland, Massachusetts and Washington shipments sales tax. Installation Instructions and Wiring Instructions.

    Features & Benefits:
  • Memory Feature (Recalls Last Set Level)
  • Compact and Lightweight
  • Supports Unlimited Single-Throw Momentary Switches
  • Two (2) Year Limited Warranty
  • Compatibility Chart

  • US$159.95 / EACH
  • Voltage Input: 10.8VDC - 30VDC
  • Power Capacity: 6.5A (80W @ 12V / 160W @24V)
  • Dimming: 10% - 100%
  • Number of Controls: Unlimited (Wired in Parallel)
  • Control Type: Momentary, Single Pole/Single Throw
  • Noise Suppression: EN55015/89/336/EEC
  • Warranty: Three (3) Years
  • Weight: 0.2 lbs.
  • Part Number: IL6183
